This welding equipment is specialized for requirement of welding technology. It has rotate motor of VFD which makes the work piece welded at the suitable position and rotating speed.
| Quantity: | |
|---|---|
HB
MiraFU
8468800000
技术参数 Technical Parameter | 型号 Model | |||||||||
HBT3 | HBT5 | HBT10 | HBT20 | HBT30 | HBT50 | HBT100 | HBT200 | |||
承载重量Max load capacity(kg) | 300 | 500 | 1000 | 2000 | 3000 | 5000 | 10000 | 20000 | ||
工作台面尺寸Worktable size(mm) | Φ600 | Φ800 | Φ1000 | Φ1200 | Φ1400 | Φ1500 | Φ1800 | Φ2000 | ||
偏心距Max eccentricity Distance(mm) | 100 | 200 | ||||||||
回转速度Rotating speed(rpm) | 0.1~1 | 0.05~0.5 | ||||||||
回转功率Rotating Power(kw) | 0.18 | 0.37 | 0.75 | 1.1 | 1.5 | |||||
调速方式Speed adjusting way | 回转变频无极调速 Rotating speed by VFD(inverter) | |||||||||
电压Voltage | 380V-50HZ-3PH(other voltage can customized) | |||||||||
可选项：1.脚踏开关 2.卡盘 3.无线遥控盒 OPTIONS:1.FOOD SWITCH 2.CHUCK 3.WIRELESS CONTROLLER | ||||||||||
