HB-12
MiraFU
8468800000
型号Model | HB12 |
承载重量Max loading capacity(kg) | 1200 |
工作台面尺寸Worktable size(mm) | Φ1200 |
偏心距Max eccentricity distance(mm) | 100 |
重心距Max gravity center distance(mm) | 200 |
翻转角度Tilting angle(°） | 0~+120 |
回转速度Rotating speed(rpm) | 0.05~0.5 |
回转功率Rotating Power(Kw) | 0.75 |
翻转速度Tilting speed(rpm) | 0.5 |
翻转功率Tilting Power(kw) | 1.1 |
调速方式Speed adjusting way | Rotating speed by VFD(INVERTER) |
电压Voltage | 380V-3PH-50HZ(Other voltage can customized) |
型号Model | HB12 |
承载重量Max loading capacity(kg) | 1200 |
工作台面尺寸Worktable size(mm) | Φ1200 |
偏心距Max eccentricity distance(mm) | 100 |
重心距Max gravity center distance(mm) | 200 |
翻转角度Tilting angle(°） | 0~+120 |
回转速度Rotating speed(rpm) | 0.05~0.5 |
回转功率Rotating Power(Kw) | 0.75 |
翻转速度Tilting speed(rpm) | 0.5 |
翻转功率Tilting Power(kw) | 1.1 |
调速方式Speed adjusting way | Rotating speed by VFD(INVERTER) |
电压Voltage | 380V-3PH-50HZ(Other voltage can customized) |
